Full Automatic 380V Gi Roller Shutter Door Slat Machine

Full Automatic 380V Gi Roller Shutter Door Slat Machine

380v roller shutter door slat machine

gi roller shutter door slat machine

rolling shutter door slats roll forming machine

उत्पत्ति के प्लेस:

चीन (महाद्वीप

ब्रांड नाम:

FMS

प्रमाणन:

ISO CE

हमसे संपर्क करें
उद्धरण मांगें
उत्पाद विवरण
प्रोडक्ट का नाम:
पूर्ण स्वचालित शटर स्लैट रोल बनाने वाली मशीन संपूर्ण उत्पादन लाइन
कच्चा माल:
पीपीजीआई, जीआई, पीपीजीएल जीएल
कार्य -गति:
10 मीटर/मिनट - 20 मीटर/मिनट उच्च गति
द्रव्य का गाढ़ापन:
0.3 मिमी - 0.8 मिमी
वोल्टेज:
380V 50Hz 3phases
स्थिति:
नया
लंबाई परिशुद्धता:
±0.3मिमी/10मी
पीएलसी:
यास्कावा, सीमेंस, मित्सुबिशी, पैनासोनिक (विकल्प ब्रांड)
प्रमुखता देना:

380v roller shutter door slat machine

,

gi roller shutter door slat machine

,

rolling shutter door slats roll forming machine

भुगतान और शिपिंग शर्तें
न्यूनतम आदेश मात्रा
1 सेट
मूल्य
negotiable
पैकेजिंग विवरण
20' एफएलसी
प्रसव के समय
30 कार्य दिवस
भुगतान शर्तें
एल/सी, टी/टी, डी/ए, डी/पी
आपूर्ति की क्षमता
प्रति माह 20 सेट
संबंधित उत्पाद
अच्छा दाम Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min ऑनलाइन वीडियो

Metal Chain Driving Shutter Door Roll Forming Machine Speed 20-30m/Min

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Customized High Speed PU Door Roller Shutter Roll Forming Machine ऑनलाइन वीडियो

Customized High Speed PU Door Roller Shutter Roll Forming Machine

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम 3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size ऑनलाइन वीडियो

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम 45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System ऑनलाइन वीडियो

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

सबसे अच्छी कीमत प्राप्त करें
हमसे संपर्क करें
86-317-2016816
अब संपर्क करें
उत्पाद वर्णन

Full Automatic Shutter Slat Roll Forming Machine Whole Production Line


Non stop cutting Shutter Door Slats Roll Forming Machine ,the service life of cutting blades exceeds 2 million times and The blade is fixed by bolts ,so it is easy to replace.
Its products are widely used in steel structure industry, building construction, vehicle industry, doors and Windows industry, transportation industry, and various projects.According to customer's required profile drawing or samples.




Specification



No.ItemDescription
1CoilGalvalume, Galvanized
2Raw MaterialPPGI,GI,PPGL GL
3Working Speed10 m/min - 20 m/min High Speed
4Material Thickness0.3 mm - 0.8mm
5Dimension (L*W*H)5500 mm*800 mm*1200 mm
6Machine Weight3.5 tons
7Electrical Control SystemDelta PLC (can be customized)
8Drive Motor Power3 KW
9Hydraulic Station Power3 KW
10Voltage380V 50Hz 3phases
11Cutting Accuracy± 1 mm
12Material of Shaft60 mm 45#steel forged




Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.
2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation


Payment terms

40% in advance as down payment
60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.

Full Automatic 380V Gi Roller Shutter Door Slat Machine 0
