Galvanized Profile C10 Steel Roofing Roll Forming Machines Metal Computerised

Galvanized Profile C10 Steel Roofing Roll Forming Machines Metal Computerised

galvanized steel roofing roll forming machines

profile steel roofing roll forming machines

computerised steel roof sheet making machine

उत्पत्ति के प्लेस:

चीन

ब्रांड नाम:

FMS

प्रमाणन:

CE,ISO

हमसे संपर्क करें
उद्धरण मांगें
उत्पाद विवरण
प्रोडक्ट का नाम:
गैल्वनाइज्ड स्टील प्रोफाइल मेटल रूफिंग रोल बनाने वाली मशीनें C10
प्रक्रिया के लिए उपयुक्त:
रंग स्टील प्लेट
रोलर सामग्री:
उच्च ग्रेड No.45 जाली इस्पात
कटर ब्लेड:
शमन उपचार के साथ CR12 मोल्ड स्टील
मशीन वजन:
4.5t
रोलर्स:
45# स्टील
काटने का ब्लेड:
CR12
वोल्टेज:
380V 50Hz 3phases
प्रमुखता देना:

galvanized steel roofing roll forming machines

,

profile steel roofing roll forming machines

,

computerised steel roof sheet making machine

भुगतान और शिपिंग शर्तें
न्यूनतम आदेश मात्रा
1 सेट
मूल्य
negotiable
पैकेजिंग विवरण
मुख्य मशीन नग्न है, कंप्यूटर नियंत्रण बॉक्स प्लास्टिक से पैक किया गया है।
प्रसव के समय
30 दिन
भुगतान शर्तें
टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता
प्रति माह 30 सेट
संबंधित उत्पाद
अच्छा दाम Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line ऑनलाइन वीडियो

Standard Corrugated Galvanized Sheets Machine Standard Corrugated Galvanized Sheets Line

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine ऑनलाइन वीडियो

Corrugated Sheet Machine Corrugated Roofing Tile Roll Forming Machine

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw ऑनलाइन वीडियो

Metal Roof Tile Trapezoidal Roll Forming Machine 5.5kw

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine ऑनलाइन वीडियो

High Material Quality C89 Light Gauge Steel Framing Building Roll Forming Machine

सबसे अच्छी कीमत प्राप्त करें
हमसे संपर्क करें
86-317-2016816
अब संपर्क करें
उत्पाद वर्णन
Galvanized Steel Profile Metal Roofing Roll Forming Machines C10


 The equipment automatically set in accordance with the computer data to produce different lengths of finished products.there is the construction of the computer controller to set up multiple sets of different data,easy operate.

This type of sheet can be widely used in plant, house, storage and simple steel roof and wall. It has advantage of pretty appearance, durable using and so on.


Equipment Detailed Parameters:

Description Specification
Main moter power 5.5KW
Hydraulic station power 4KW
Hydraulic oil pump CB-E310
Sprocket P-25.4
Roller station 14
Yield strength 32MPa
Diameter of principal axis 95MM
Material of roller 45#steel hard chrome plating
Processing speed 8m/min
Thickness 0.3-1mm
Installation dimension about(L*W*H) 7.5*1.5*1.2M
Total weight 3.8T


Guarantee



1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation



Payment terms



40% in advance as down payment

60% is paid before the shipment is processed



Delivery



FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
