उत्पत्ति के प्लेस:
चीन
ब्रांड नाम:
FMS
प्रमाणन:
CE,ISO
वीडियो
With Standare punch & die for bending angle larger or equal to 90 degree .Our press brake backgauge with accurate ball screw and liner guide which will greatly improve bending accuracy .Optional Updated Z stopper & solid backgauge beam with double rail to meet mult bending needs .With imported Siemenz main motor for WC67K -63T/2500 plate Hydraulic CNC Press Brake for hot sale.With Traditional button to control machine movement direction simplifying your operation.
Equipment Detailed Parameters:
| No. | Main parameter | |
| 1 | Suitable to process | color steel plate, steel plate, galvanized sheet and so an. |
| 2 | Raw material thickness | 0.2-1.0mm |
| 3 | Bending Thickness | This bending machine can bend the thickness less than 2.0mm. |
| 4 | Motor power | 3KW |
| 5 | length | 2.5 meter |
| 6 | Weight | about 2.3Tons |
| 7 | Warranty of core components | 1 Year |
| 8 | Voltage | 380V 50Hz 3phases |
| 9 | Core Components | Motor, PLC |
| 10 | dimension | 4200*800*1600mm |
Guarantee
1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.
2. Repairs will not be performed even during the guarantee period in the follow circumstances
- Damage occurs due to a natural disaster
- Malfunction occurs due to user error
- Malfunction occurs due to modifications
- Malfunction occurs due to further movement or shipment after installation
Payment terms
40% in advance as down payment
60% is paid before the shipment is processed
Delivery
FOB: Tianjin Xingang Port
The Delivery Time: 30 days after the down payment is received.
