Trapezoid Steel Roof PPGL Wall Panel Roll Forming Machine 3phases

Trapezoid Steel Roof PPGL Wall Panel Roll Forming Machine 3phases

ppgl wall panel roll forming machine

3phases wall panel roll forming machine

ppgl trapezoidal roll forming machine

उत्पत्ति के प्लेस:

चीन (महाद्वीप

ब्रांड नाम:

FMS

प्रमाणन:

ISO CE

हमसे संपर्क करें
उद्धरण मांगें
उत्पाद विवरण
प्रोडक्ट का नाम:
ट्रेपेज़ॉइड स्टील पैनल रोल बनाने की मशीन छत की दीवार पैनल रोल बनाने की मशीन
सामग्री:
जीआई, जीएल, पीपीजीएल, पीपीजीआई
रोलर:
क्रोम मढ़वाया
विनिर्देश:
9.5*1.45*1.5
वज़न:
4500 किलोग्राम
मुख्य घटकों की वारंटी:
1 वर्ष
वोल्टेज:
380V 50Hz 3चरण, 380V 50Hz 3चरण
बाद में:
कमीशनिंग और इंस्टालेशन कार्य प्रदान करें
प्रमुखता देना:

ppgl wall panel roll forming machine

,

3phases wall panel roll forming machine

,

ppgl trapezoidal roll forming machine

भुगतान और शिपिंग शर्तें
न्यूनतम आदेश मात्रा
1 सेट
मूल्य
negotiable
पैकेजिंग विवरण
40' एफएलसी
प्रसव के समय
30 कार्य दिवस
भुगतान शर्तें
एल/सी, टी/टी, डी/ए, डी/पी
आपूर्ति की क्षमता
प्रति माह 20 सेट
संबंधित उत्पाद
अच्छा दाम 2025 New Design Metal Picket Fence Roll Forming Machine Fence Lines America Style ऑनलाइन वीडियो

2025 New Design Metal Picket Fence Roll Forming Machine Fence Lines America Style

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Corrugated Container Board 15m/Min Wall Panel Roll Forming Machine Fully Automatic ऑनलाइन वीडियो

Corrugated Container Board 15m/Min Wall Panel Roll Forming Machine Fully Automatic

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Trapezoid Steel Roof PPGL Wall Panel Roll Forming Machine 3phases ऑनलाइन वीडियो

Trapezoid Steel Roof PPGL Wall Panel Roll Forming Machine 3phases

सबसे अच्छी कीमत प्राप्त करें
अच्छा दाम Iron 0.8mm Corrugated Roofing Sheet Roll Forming Machine Hydraulic Cut ऑनलाइन वीडियो

Iron 0.8mm Corrugated Roofing Sheet Roll Forming Machine Hydraulic Cut

सबसे अच्छी कीमत प्राप्त करें
हमसे संपर्क करें
अब संपर्क करें
उत्पाद वर्णन

Container Body Car Carriage Board Panel Cold Roll Forming Machine Plc Control



Trapezoid Steel Panel Roll Forming Machine Roof Wall Panel Roll Forming is the equipment that mainly produces trapezoidal sheet. Trapezoidal plates are very common in our daily lives. You can see that they are used in various fields, such as workshop, warehouse, carport, wall board, portable house, then why is it so widely used? Compared with traditional tiles, it has many advantages, such as light weight, high strength, heat insulation, easy installation, bright colors and waterproof, but at the same time it also has some small defects, such as sound insulation because of its thin thickness. The effect is relatively poor, and the ability to resist wind and cold is relatively poor, and it is easy to rust after a long period of rain and it is not easy to recycle.



Specification

1 Width of the plate 1219mm
2 Rollers 18 Rows
4 Power 11+11+7.5kw
5 Thickness of the plate 0.8-1.2mm
6 Productivity 0-15m/min
7 Diameter of the roller 90mm
8 Weight About4500kg
9 Voltage 380V 50Hz 3phases
10 Material of the cutting plate Cr12
11 Hydraulic 40#
12 Processing precision Within 1.00mm
13 Control system PLC control


Guarantee



1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation



Payment terms



40% in advance as down payment

60% is paid before the shipment is processed



Delivery



FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
