100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic

100MM Downspout Roll Forming Machine

Round Downspout Roll Forming Machine

Automatic Downspout Roll Forming Machine

उत्पत्ति के प्लेस:

चीन

ब्रांड नाम:

CANGZHOU FMS

प्रमाणन:

ISO CE

मॉडल संख्या:

डाउन पाइप रोल बनाने की मशीन

हमसे संपर्क करें
उद्धरण मांगें
उत्पाद विवरण
प्रोडक्ट का नाम:
100 एमएम कलर स्टील राउंड डाउनस्पाउट रोल बनाने वाली मशीन मेटल ऑटोमैटिक
उत्पादन क्षमता:
13-15 मीटर/मिनट
वज़न:
6850 किग्रा
खिला चौड़ाई:
500 मिमी
आयाम(एल*डब्ल्यू*एच):
7.5*1.65*1.5 मी
मशीन की मुख्य शक्ति:
5.5 kw
वोल्टेज:
380V 50Hz 3चरण या आवश्यकता के अनुसार
स्वचालन:
पूर्ण स्वत:
रोलिंग मोटाई:
0.4-0.8 मिमी
प्रमुखता देना:

100MM Downspout Roll Forming Machine

,

Round Downspout Roll Forming Machine

,

Automatic Downspout Roll Forming Machine

भुगतान और शिपिंग शर्तें
न्यूनतम आदेश मात्रा
1 सेट
मूल्य
negotiable
पैकेजिंग विवरण
20' एफएलसी
प्रसव के समय
30 कार्य दिवस
भुगतान शर्तें
एल/सी, टी/टी, डी/ए, डी/पी
आपूर्ति की क्षमता
प्रति माह 20 सेट
संबंधित उत्पाद
हमसे संपर्क करें
अब संपर्क करें
उत्पाद वर्णन

100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic ​


100 MM Color Steel Round Downspout Roll Forming Machine Metal Automatic Work Flow
    Decoiler→Manual Pre-Cutter→Guide Feeding →Roll Forming System→Hydraulic Post Cutter →Exit Rack



Downspout roll forming machine, known as rainwater downpipe roll forming machine as well, has been designed for making square or round (circle or rectangular) rainwater pipes. downspout has many different names as, waterspout, downpipe, drain spout, and roof drain pipe etc

Our downspout roll forming machine is special for manufacturing various size round downspout and rectangular downspout pipe.Downspout (Down pipe) is a pipe for conveying rain water from a roof or gutter to the ground or to a drain., also referred to as Leaderpipe, Downpipe, or Drainspout. The downspouts are more and more widely applied in rain water storage solution.


Specification

Tile Type
Colored Steel
Use
ROOF
Dimension(L*W*H)
7.5*1.65*1.5m
Weight
6850kg
Warranty
2 years
Key Selling Points
High Productivity
Rolling thinckness
0.4-0.8 mm
Warranty of core components
1.5 years
Core Components
Motor, Bearing, PLC
Product name
Downspout Roll Forming Machine
Color
Client's Request
Cutting blade material
Cr12 Quenched
Control system
Fully Automatic Computer Control




Installation


   During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.



Guarantee



  The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).



Payment terms



  40% in advance

  60% is paid before shipping
