Name: 2025 New Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: मिनी स्वचालित स्लिटिंग लाइन
Price: 26,500.00 USD
Availability: InStock

घर > उत्पादों > लंबाई और स्लिटिंग लाइन में कटौती >

2025 New Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

high speed slitter slitting line machine

hydraulic uncoiler slitting line

40m/min slitting line with recoiler

उत्पत्ति के प्लेस:

चीन (महाद्वीप

ब्रांड नाम:

FAMOUSE

प्रमाणन:

ISO, CE

मॉडल संख्या:

मिनी स्वचालित स्लिटिंग लाइन

हमसे संपर्क करें

उद्धरण मांगें

उत्पाद विवरण

प्रोडक्ट का नाम:

हाइड्रोलिक अनकॉइलर और रिकॉइलर के साथ सरल हाई स्पीड मिनी स्लिटर स्लिटिंग लाइन

काटने की सामग्री:

गैलवेल्यूम, गैल्वेनाइज्ड, पीपीजीआई, एल्युमीनियम

द्रव्य का गाढ़ापन:

0.3 मिमी -3 मिमी

कार्य -गति:

8 मीटर/मिनट - 30 मीटर/मिनट (अनुकूलित किया जा सकता है)

कुंडल वजन:

5 टन / 7 टन / 10 टन (अनुकूलित किया जा सकता है)

स्लाटिंग पीसी:

2 - 30 पीसी

मशीन वजन:

13000 किग्रा

काटने की चौड़ाई परिशुद्धता:

± 0.01 - ± 0.05 मिमी

प्रमुखता देना:

high speed slitter slitting line machine

hydraulic uncoiler slitting line

40m/min slitting line with recoiler

भुगतान और शिपिंग शर्तें

न्यूनतम आदेश मात्रा

1 सेट उत्पादन लाइन

मूल्य

negotiable

पैकेजिंग विवरण

2 पीसी 40' एफएलसी

प्रसव के समय

60 कार्य दिवस

भुगतान शर्तें

एल/सी, डी/ए, डी/पी, टी/टी

आपूर्ति की क्षमता

प्रति 60 दिनों में 5 सेट

संबंधित उत्पाद

वीडियो

2025 Factory Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

सबसे अच्छी कीमत प्राप्त करें

वीडियो

2025 New Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

सबसे अच्छी कीमत प्राप्त करें

Steel Metal Heavy Thickness Coil Leveling 1.5mm 1200mm PPGI Cut To Length

सबसे अच्छी कीमत प्राप्त करें

वीडियो

steel coile 40m/min High Speed Slitting Line Machine With Hydraulic Uncoiler And Recoiler

सबसे अच्छी कीमत प्राप्त करें

हमसे संपर्क करें

86-317-2016816

अब संपर्क करें

उत्पाद वर्णन

2025 New Price 40m/min High Speed Slitter Slitting Line Machine With Hydraulic Uncoiler And Recoiler

The mini slitter line can become an ideal support if the product includes a great variety of coils with reduced widths in which it is certainly not economical to use a large line for cutting coils under 300 mm and especially when very reduced spaces are necessary because of the product type.

Product Specifications

Attribute	Value
Product Name	Simple High Speed Mini Slitter Slitting Line With Hydraulic Uncoiler And Recoiler
Cutting Material	Galvalume, Galvanized, PPGI, Aluminum
Material Thickness	0.3 mm - 3 mm
Working Speed	8 m/min - 30 m/min (can be customized)
Coil Weight	5 tons / 7 tons / 10 tons (can be customized)
Slitting Pcs	2 - 30 pcs
Machine Weight	13000 KG
Cutting Width Precision	± 0.01 - ± 0.05 mm

Main Technical Specifications

No.	Item	Description
1	Main Specification	Raw Material: Galvanized, Aluminum, Color steel, Hardness 235MPa - 485MPa Raw Material Thickness: 0.3 mm - 3.0 mm Raw Material Width: 600 mm - 1600 mm Tape Inner Diameter: φ 480 mm - φ 530 mm Tape Outer Diameter: φ 1600 mm Coil Weight: 5 tons - 10 tons Slitting No.: Max 30 pcs The Highest Slitting Line Speed: 8 m/min - 30 m/min Minimum Cutting Line Width: 35 mm Cutting Width Precision: ± 0.01 - ± 0.05 mm Rated Operational Voltage: 240 V, 3 Phase, 60 Hz Total Weight: 13000 KG Working Space (LW): 20000 mm6000 mm
2	Decoiler Machine Specification	Tape Outer Diameter: Max φ 1600 mm Tape Width: 600 mm - 1600 mm Tape Inner Diameter: φ 480 mm - φ 530 mm Coil Weight: 5 tons - 10 tons Max Working Speed: 8 m/min - 30 m/min Tape Tight Range: φ 480 mm - φ 530 mm Shaft Diameter: φ180 mm Roller Effective Length: 1600 mm Drive Motor Power: 5.5 KW Loading Car Diameter: φ 700 mm - φ 1500 mm Loading Car Weight: 5 tons - 10 tons Car Speed: About 4 m/min
4	Slitting Machine Specification	Cutting Width: Max φ 1600 mm Cutting Thickness: 0.3 mm - 2.0 mm Cutter Shaft Diameter: φ180 mm Cutter Shaft Material: Cr 40 Cutter Size: 200 mm300 mm15 mm Cutter Material: Cr12MoV Cutter Spacer Size: 180 mm240 mm15 mm Drive Motor: 15 kw Cutting No.: 2-30 pcs Cutter No.: Max 32 pcs
7	Recoiler Specification	Tape Outer Diameter: Max φ 1600 mm Tape Width: 600 mm - 1600 mm Tape Inner Diameter: φ 480 mm - φ 530 mm Coil Weight: 5 - 10 tons Max Working Speed: 8 m/min - 30 m/min Tape Tight Range: φ 485 mm - φ 530 mm Shaft Diameter: φ 180 mm Roller Effective Length: 1750 mm Drive Motor Power: 30 kw Loading Car Diameter: φ 1000 mm - φ 1750 mm Loading Car Weight: Max 10 tons Car Speed: About 4 m/min
9	Electrical Control System	2 sets. Computer Control System is Siemens PLC.
10	Edge Collecting Machine	Drive Motor: 3 kw Collecting Material Width: Max 20 mm Double Edge Width: 400 mm

Recommended Applications

Recommended for producing narrow coils, but especially a fast line for small spaces and particularly suitable for brass, copper, aluminium, tinfoil and lamination steel but also for cold-rolled, galvanized and prepainted materials and stainless steel.

Guarantee

Guaranteed against malfunctions due to manufacturing defects for 1 years after date of purchase except Electrical parts.
Repairs will not be performed even during the guarantee period in the follow circumstances:
- Damage occurs due to a natural disaster
- Malfunction occurs due to user error
- Malfunction occurs due to modifications
- Malfunction occurs due to further movement or shipment after installation
